5305-00-004-3158, 5305000043158 NSN Information

Request for Quote

Manufacturer Part Number(s):

FSC NIIN ITEM NAME
5305 000043158 SCREW,EXTERNALLY RELIEVED BODY
INC ESDC HMIC


5305-00-004-3158 MCRD (Master Cross Reference Data)

Mfg. Part # Mfg. Name CAGE RNCC RNVC ISC MSDS SADC DAC HCC
20794-5 ORDNANCE CORPS 0EER9 C 1 2 9X
20794-5 ORDNANCE CORPS 9344 3 2 2
20794-5 ORDNANCE CORPS 56563 5 9 2

5305-00-004-3158 Characteristics

MRC Requirement Statement Characteristics
AAWH DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FIRST DIAMETER 0.277 INCHES MINIMUM AND 0.287 INCHES MAXIMUM
CSNG EXTERNALLY RELIEVED BODY DIAMETER QUANTITY 1
AASB FASTENER LENGTH 0.428 INCHES MINIMUM AND 0.448 INCHES MAXIMUM
AAWC FIRST DIAMETER FROM HEAD 0.081 INCHES MINIMUM AND 0.091 INCHES MAXIMUM
AASL HEAD DIAMETER 0.256 INCHES MINIMUM AND 0.270 INCHES MAXIMUM
AASU HEAD HEIGHT 0.087 INCHES MINIMUM AND 0.097 INCHES MAXIMUM
AASK HEAD STYLE PAN
MATT MATERIAL STEEL COMP 304L OVERALL OR STEEL COMP 316L OVERALL OR STEEL COMP 302 OVERALL OR STEEL COMP 347 OVERALL OR STEEL COMP 321 OVERALL OR STEEL COMP 317 OVERALL OR STEEL COMP 316 OVERALL OR STEEL COMP 310 OVERALL OR STEEL COMP 309 OVERALL OR STEEL COMP 305 OVER
AHYM NOMINAL THREAD DIAMETER 0.138 INCHES
ABQZ INTERNAL DRIVE STYLE CROSS RECESS TYPE 1
STDC SURFACE TREATMENT DOCUMENT AND CLASSIFICATION MIL-C-13924 CL 4 MIL SPEC SINGLE TREATMENT RESPONSE OVERALL
SFTT SURFACE TREATMENT OXIDE OVERALL
AASA THREAD LENGTH 0.141 INCHES MINIMUM AND 0.171 INCHES MAXIMUM
AAJD THREAD CLASS 2A
AAJF THREAD DIRECTION RIGHT-HAND
CMLP THREAD QUANTITY PER INCH 32
THSD THREAD SERIES DESIGNATOR UNC
