5305-00-004-3159, 5305000043159 NSN Information

Request for Quote

Manufacturer Part Number(s):

FSC NIIN ITEM NAME
5305 000043159 SCREW,EXTERNALLY RELIEVED BODY
INC ESDC HMIC


5305-00-004-3159 MCRD (Master Cross Reference Data)

Mfg. Part # Mfg. Name CAGE RNCC RNVC ISC MSDS SADC DAC HCC
20794-7 ROCKWELL COLLINS, INC. 9344 3 2 5

5305-00-004-3159 Characteristics

MRC Requirement Statement Characteristics
AAWH DISTANCE FROM LARGEST BEARING SURFACE OF HEAD TO END OF FIRST DIAMETER 0.339 INCHES MINIMUM AND 0.349 INCHES MAXIMUM
CSNG EXTERNALLY RELIEVED BODY DIAMETER QUANTITY 1
AASB FASTENER LENGTH 0.552 INCHES MINIMUM AND 0.572 INCHES MAXIMUM
AAWC FIRST DIAMETER FROM HEAD 0.085 INCHES MINIMUM AND 0.095 INCHES MAXIMUM
AASL HEAD DIAMETER 0.205 INCHES MINIMUM AND 0.219 INCHES MAXIMUM
AASU HEAD HEIGHT 0.070 INCHES MINIMUM AND 0.080 INCHES MAXIMUM
AASK HEAD STYLE PAN
MDCL MATERIAL DOCUMENT AND CLASSIFICATION QQ-S-763 300 SERIES COND A FED SPEC ALL MATERIAL RESPONSES OVERALL
MATT MATERIAL STEEL COMP 304L OR STEEL COMP 316L OR STEEL COMP 302 OR STEEL COMP 347 OR STEEL COMP 321 OR STEEL COMP 317 OR STEEL COMP 316 OR STEEL COMP 310 OR STEEL COMP 309 OR STEEL COMP 305 OR STEEL COMP 304 OVERALL
AHYM NOMINAL THREAD DIAMETER 0.112 INCHES
CXCY III PART NAME ASSIGNED BY CONTROLLING AGENCY NAVY SPECIAL PROJECT
ABQZ INTERNAL DRIVE STYLE CROSS RECESS TYPE 1
STDC SURFACE TREATMENT DOCUMENT AND CLASSIFICATION QQ-P-35 TYPE 2 FED SPEC SINGLE TREATMENT RESPONSE OVERALL
SFTT SURFACE TREATMENT PASSIVATE OVERALL
AASA THREAD LENGTH 0.203 INCHES MINIMUM AND 0.233 INCHES MAXIMUM
AAJD THREAD CLASS 2A
AAJF THREAD DIRECTION RIGHT-HAND
CMLP THREAD QUANTITY PER INCH 40
THSD THREAD SERIES DESIGNATOR UNC
