| MRC |
Requirement Statement |
Characteristics |
| AASB |
FASTENER LENGTH |
1.438 INCHES MINIMUM AND 1.500 INCHES MAXIMUM |
| CQFM |
HARDNESS RATING |
235.0 BRINELL STANDARD MAXIMUM OVERALL |
| AASU |
HEAD HEIGHT |
0.378 INCHES MINIMUM AND 0.403 INCHES MAXIMUM |
| AAUB |
HOLE DIAMETER |
0.094 INCHES NOMINAL |
| CRHC |
HOLE CONFIGURATION STYLE |
HEXAGON LONGITUDINAL HOLE |
| ASXK |
HOLE QUANTITY |
1 |
| BQDM |
HOLE TYPE |
DRILLED |
| MATT |
MATERIAL |
STEEL COMP 403 OVERALL OR STEEL COMP 405 OVERALL OR STEEL COMP 410 OVERALL OR STEEL COMP 410 OVERALL OR STEEL COMP 416 OVERALL OR STEEL COMP 416 PLUS X OVERALL OR STEEL COMP 416F OVERALL OR STEEL COMP 416SE OVERALL OR STEEL COMP 420 OVERALL OR STEEL COMP |
| CQBC |
MINIMUM TENSILE STRENGTH |
70000 POUNDS PER SQUARE INCH |
| CQHQ |
MINIMUM YIELD STRENGTH |
40000 POUNDS PER SQUARE INCH |
| AHYM |
NOMINAL THREAD DIAMETER |
0.625 INCHES |
| ZZZT |
NONDEFINITIVE SPEC/STD DATA |
2 TYPE AND 10P STYLE |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
FED. STD 66 FED STD ALL MATERIAL RESPONSES OVERALL |
| AATB |
WIDTH BETWEEN FLATS |
0.922 INCHES MINIMUM AND 0.938 INCHES MAXIMUM |
| AASK |
|
|
| CSYM |
SURFACE FINISH |
63.0 MICROINCHES THREADS |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
PASSIVATE OVERALL |
| AAJD |
THREAD CLASS |
2A |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
1.275 INCHES MINIMUM AND 1.500 INCHES MAXIMUM |
| CMLP |
THREAD QUANTITY PER INCH |
11 |
| THSD |
THREAD SERIES DESIGNATOR |
UNC |
