| MRC |
Requirement Statement |
Characteristics |
| AASB |
FASTENER LENGTH |
1.928 INCHES MINIMUM AND 2.000 INCHES MAXIMUM |
| CQFM |
HARDNESS RATING |
26.0 ROCKWELL C MINIMUM OVERALL AND 32.0 ROCKWELL C MAXIMUM OVERALL |
| AASU |
HEAD HEIGHT |
0.302 INCHES MINIMUM AND 0.323 INCHES MAXIMUM |
| AASK |
HEAD STYLE |
HEXAGON |
| CRHC |
HOLE CONFIGURATION STYLE |
HEXAGON FLATS |
| AAUB |
HOLE DIAMETER |
0.060 INCHES MINIMUM AND 0.068 INCHES MAXIMUM |
| ASXK |
HOLE QUANTITY |
3 |
| BQDM |
HOLE TYPE |
DRILLED |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
QQ-S-763 COND A COLD FINISH FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| MATT |
MATERIAL |
STEEL COMP 410 OVERALL |
| AHYM |
NOMINAL THREAD DIAMETER |
0.500 INCHES |
| AATB |
WIDTH BETWEEN FLATS |
0.736 INCHES MINIMUM AND 0.750 INCHES MAXIMUM |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-416,TYPE 2 CLASS 3 FED SPEC ALL TREATMENT RESPONSES OVERALL |
| SFTT |
SURFACE TREATMENT |
CADMIUM OVERALL AND CHROMATE OVERALL |
| AAJD |
THREAD CLASS |
2A |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
1.250 INCHES MINIMUM AND 1.440 INCHES MAXIMUM |
| CMLP |
THREAD QUANTITY PER INCH |
13 |
| THSD |
THREAD SERIES DESIGNATOR |
UNC |
