| MRC |
Requirement Statement |
Characteristics |
| CQWR |
EXTERNAL THREAD TOLERANCE CLASS |
6H |
| AASB |
FASTENER LENGTH |
25.0 MILLIMETERS NOMINAL |
| CQFM |
HARDNESS RATING |
39.0 ROCKWELL C MINIMUM OVERALL AND 48.0 ROCKWELL C MAXIMUM OVERALL |
| AASU |
HEAD HEIGHT |
6.170 MILLIMETERS MINIMUM AND 6.630 MILLIMETERS MAXIMUM |
| AASK |
HEAD STYLE |
HEXAGON |
| MATT |
MATERIAL |
STEEL CORROSION RESISTING OVERALL |
| AHYM |
NOMINAL THREAD DIAMETER |
10.0 MILLIMETERS |
| FEAT |
SPECIAL FEATURES |
SCREW SHALL BE IN ACCORDANCE WITH REQUIREMENTS OF ANSI B18.2.3 IM EXCEPT MATERIAL SHALL BE CORROSION RESISTING STEEL. |
| AATB |
WIDTH BETWEEN FLATS |
15.0 MILLIMETERS NOMINAL |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-35 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
PASSIVATE OVERALL |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
30.0 MILLIMETERS MAXIMUM |
| CQQR |
THREAD PITCH IN MILLIMETERS |
1.5 |
| THSD |
THREAD SERIES DESIGNATOR |
M |
