| MRC |
Requirement Statement |
Characteristics |
| ZZZW |
DEPARTURE FROM CITED DOCUMENT |
AS MODIFIED BY MATERIAL |
| AASB |
FASTENER LENGTH |
1.500 INCHES NOMINAL |
| AASU |
HEAD HEIGHT |
0.226 INCHES MINIMUM AND 0.243 INCHES MAXIMUM |
| AASK |
HEAD STYLE |
HEXAGON |
| MATT |
MATERIAL |
STEEL COMP 316 OVERALL |
| CQBC |
MINIMUM TENSILE STRENGTH |
105000 POUNDS PER SQUARE INCH |
| CQHQ |
MINIMUM YIELD STRENGTH |
65000 POUNDS PER SQUARE INCH |
| AHYM |
NOMINAL THREAD DIAMETER |
0.375 INCHES |
| ZZZT |
NONDEFINITIVE SPEC/STD DATA |
1 TYPE AND 316 GRADE |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
ASTM F593 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| AATB |
WIDTH BETWEEN FLATS |
0.551 INCHES MINIMUM AND 0.562 INCHES MAXIMUM |
| ZZZK |
SPECIFICATION/STANDARD DATA |
81349--1222RX6C224SCNN GOVERNMENT SPECIFICATION |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
ASTM A380 ASSN STD SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
PASSIVATE OVERALL |
| AAJD |
THREAD CLASS |
2A |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| AASA |
THREAD LENGTH |
1.000 INCHES NOMINAL |
| CMLP |
THREAD QUANTITY PER INCH |
16 |
| THSD |
THREAD SERIES DESIGNATOR |
UNC |
