| MRC |
Requirement Statement |
Characteristics |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
MIL-S-6758 MIL SPEC SINGLE MATERIAL RESPONSE OVERALL |
| MATT |
MATERIAL |
STEEL COMP 4130 OVERALL |
| CSXB |
KEY CHAMFER ANGLE |
45.0 DEGREES NOMINAL |
| ACJF |
KEY CHAMFER LENGTH |
0.177 INCHES MINIMUM AND 0.197 INCHES MAXIMUM |
| ABKW |
OVERALL HEIGHT |
0.375 INCHES MINIMUM AND 0.376 INCHES MAXIMUM |
| ABHP |
OVERALL LENGTH |
1.000 INCHES NOMINAL |
| ABMK |
OVERALL WIDTH |
0.177 INCHES MINIMUM AND 0.197 INCHES MAXIMUM |
| CSPJ |
STARTING EDGE SHAPE |
CHAMFERED |
| STYL |
STYLE DESIGNATOR |
PLAIN |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-416,CL 1,TY 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
CADMIUM OVERALL AND PHOSPHATE OVERALL |
