| MRC |
Requirement Statement |
Characteristics |
| ABCJ |
COLLAR INSIDE DIAMETER |
0.252 INCHES MINIMUM AND 0.261 INCHES MAXIMUM |
| ABAA |
COLLAR OUTSIDE DIAMETER |
0.408 INCHES MINIMUM AND 0.412 INCHES MAXIMUM |
| ABAB |
COLLAR OVERALL HEIGHT |
0.532 INCHES MINIMUM AND 0.552 INCHES MAXIMUM |
| CWBJ |
COLLAR STYLE |
THREADED (BREAK OFF) TYPE |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
QQ-S-764 FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| MATT |
MATERIAL |
STEEL COMP 303SE OVERALL |
| CQJX |
NOMINAL THREAD SIZE |
0.250 INCHES |
| ABAJ |
LUBRICATION |
GREASE FILM |
| THSD |
THREAD SERIES DESIGNATOR |
UNJF |
| STDC |
SURFACE TREATMENT DOCUMENT AND CLASSIFICATION |
QQ-P-416,TYPE 1,CLASS 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT |
SURFACE TREATMENT |
CADMIUM OVERALL |
| AAJD |
THREAD CLASS |
3B |
| AAJF |
THREAD DIRECTION |
RIGHT-HAND |
| CMLP |
THREAD QUANTITY PER INCH |
28 |
