| MRC |
Requirement Statement |
Characteristics |
| ANEE |
GRIP LENGTH |
0.610 INCHES MAXIMUM |
| AASU |
HEAD HEIGHT |
0.067 INCHES MINIMUM AND 0.077 INCHES MAXIMUM |
| AAZG |
HEAD MAJOR DIAMETER |
0.296 INCHES MINIMUM AND 0.328 INCHES MAXIMUM |
| AASK |
HEAD STYLE |
COUNTERSUNK W/PROTRUDING STUD |
| MATT |
MATERIAL |
STEEL CORROSION RESISTING OVERALL |
| AAZE |
SHANK DIAMETER |
0.172 INCHES MINIMUM AND 0.176 INCHES MAXIMUM |
| AAZF |
SHANK STYLE |
PIN-RIVET, MULTIPLE GROOVED |
| CXCY |
PART NAME ASSIGNED BY CONTROLLING AGENCY |
RIVET,BLIND |
| FEAT |
SPECIAL FEATURES |
AB RIVET: WIREDRAW-1/64 INCH OVERSIZE UNIVERSAL HEAD HOLE LIMITS: 0.176 INCH MINIMUM,0.180 INCH MAXIMUM GRIP RANGE: 0.126 INCH MINIMUM,0.187 INCH MAXIMUM |
