| Mfg. Part # | Mfg. Name | CAGE | RNCC | RNVC | ISC | MSDS | SADC | DAC | HCC |
|---|---|---|---|---|---|---|---|---|---|
| SV4F2 | SENIOR OPERATIONS LLC | 3024 | 3 | 2 | 2 | ||||
| GS520N2 | SENIOR OPERATIONS LLC | 26512 | 5 | 2 | 2 |
| MRC | Requirement Statement | Characteristics |
|---|---|---|
| AGRF | DISTANCE FROM ENGAGING MEMBER TO LARGEST BEARING SURFACE OF HEAD | 0.680 INCHES NOMINAL |
| AKCV | DRIVE TYPE | CROSS RECESS |
| ABMZ | DIAMETER | 0.519 INCHES NOMINAL |
| AGRK | EYELET LENGTH | 0.200 INCHES NOMINAL |
| MATT | MATERIAL | STEEL OVERALL |
| ADQB | SECURING DEVICE TYPE | RING |
| AGRD | TURNLOCK STUD HEAD STYLE | FLAT COUNTERSUNK |
| AGRE | STUD ASSEMBLY STYLE | STUD ASSEMBLY |
| ALBJ | STUD THREAD SIZE AND SERIES/TYPE DESIGNATOR | BUTTRESS 1/4-20-02 |
| STDC | SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416 TY 2 CL 3 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| SFTT | SURFACE TREATMENT | CADMIUM AND CHROMATE OVERALL |
