| MRC |
Requirement Statement |
Characteristics |
| AZDC |
DISTANCE FROM LOOP CENTER TO TONGUE END |
0.748 INCHES NOMINAL |
| AZCY |
CENTER TO CENTER DISTANCE BETWEEN LOOP AND MOUNTING HOLE |
0.560 INCHES NOMINAL |
| AAAP |
CUSHIONING ENVIRONMENTAL PROTECTION |
ANY ACCEPTABLE |
| ABMZ |
DIAMETER |
0.201 INCHES MINIMUM AND 0.209 INCHES MAXIMUM |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
QQ-A-S250/5 T4 FED SPEC SINGLE MATERIAL RESPONSE BAND |
| ABPX |
MATERIAL THICKNESS |
0.029 INCHES MINIMUM AND 0.035 INCHES MAXIMUM |
| MATT |
MATERIAL |
ALUMINUM ALLOY 2024 BAND |
| MATT |
MATERIAL |
PLASTIC POLYTETRAFLUOROETHYLENE CUSHION |
| BZTN |
LOOP INSIDE DIAMETER |
0.438 INCHES NOMINAL |
| ABMK |
OVERALL WIDTH |
0.375 INCHES NOMINAL |
| AAAL |
TONGUE HOLE TYPE |
ROUND, UNTHREADED |
| STYL |
STYLE DESIGNATOR |
OFFSET MOUNT |
| SFTT |
SURFACE TREATMENT |
ANODIZE BAND |
