| MRC |
Requirement Statement |
Characteristics |
| APGF |
DESIGN TYPE |
THREADED |
| MATT |
MATERIAL |
PLASTIC |
| BZMQ |
INSIDE DIAMETER LENGTH |
1.323 INCHES NOMINAL |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
L-P-390, TYPE 1, CLASS L, GRADE 1 FED SPEC SINGLE MATERIAL RESPONSE |
| BZMX |
ROUND CAP OUTSIDE SURFACE CONDITION |
RIBBED |
| ADAV |
OVERALL DIAMETER |
1.354 INCHES NOMINAL |
| THDS |
THREAD SIZE AND SERIES/TYPE DESIGNATOR |
1-5/16-12 UN |
| ASDB |
WIDTH ACROSS FLATS |
0.926 INCHES MINIMUM AND 0.986 INCHES MAXIMUM |
| ZZZK |
SPECIFICATION/STANDARD DATA |
80205-NAS814 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
| AAJD |
THREAD CLASS |
2B |
