| MRC |
Requirement Statement |
Characteristics |
| AZDC |
DISTANCE FROM LOOP CENTER TO TONGUE END |
0.335 INCHES NOMINAL |
| AZCY |
CENTER TO CENTER DISTANCE BETWEEN LOOP AND MOUNTING HOLE |
0.150 INCHES MINIMUM AND 0.270 INCHES MAXIMUM |
| ABMZ |
DIAMETER |
0.091 INCHES MINIMUM AND 0.101 INCHES MAXIMUM |
| ABPX |
MATERIAL THICKNESS |
0.030 INCHES NOMINAL |
| MATT |
MATERIAL |
PLASTIC POLYAMIDE OVERALL |
| BZTN |
LOOP INSIDE DIAMETER |
0.125 INCHES NOMINAL |
| MDCL |
MATERIAL DOCUMENT AND CLASSIFICATION |
L-P-410 FED SPEC SINGLE MATERIAL RESPONSE OVERALL |
| ABMK |
OVERALL WIDTH |
0.146 INCHES MINIMUM AND 0.166 INCHES MAXIMUM |
| FEAT |
SPECIAL FEATURES |
MATING SERRATED SURFACES BETWEEN TONGUE SEGMENTS |
| AAAL |
TONGUE HOLE TYPE |
ROUND, UNTHREADED |
| ZZZK |
SPECIFICATION/STANDARD DATA |
80205-NAS1397 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
| STYL |
STYLE DESIGNATOR |
SINGLE LOOP |
